Key Features
- Intel Processor
- Max 8 IP Camera Inputs with IVS Recording
- Max 180 Mbps Incoming Bandwidth
- Up to 8MP Resolution for Preview and Playback
- Smart Tracking
- Dual-OS Design to Ensure High Reliability of System Running
- 264+ Compression Effectively Reduces the Storage Space and Costs by up to 50%
- HDMI/VGA Outputs Provided
- Up to 2 SATA Interfaces Connectable for Recording and Backup
| Specification | |
|---|---|
| System | |
| Main Processor: | Dual Core Embedded Processor |
| Incoming/Outgoing Bandwidth: | Embedded LINUX |
| Video & Audio Input | |
| Operating System: | 180/180 MBPS |
| IP Camera Input: | 8 Channel Up to 8 MP |
| 2 Way Talk: | 1 Ch Input/ 1 Ch Output RCA |
| Video & Audio Output | |
| Recording Resolution: | 8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/ DCIF/2CIF/CIF/QCIF |
| VGA /HDMI Output Resolution: | 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 ×768/60Hz |
| Audio Output: | 2-Ch, RCA (2.0Vp-p, 1 KΩ),8CH IPC audio Input |
| Display | |
| Decoding Format: | H.265+/H.265/H.264/H.264+/MPEG4 |
| Live View: | 8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/ VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Playback Resolution: | 8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/ VGA/4CIF/DCIF/2CIF/CIF/QCIF,960P,720P real time |
| Display Split: | 1/4/8/9 |
| Synchronous Playback: | 8 Ch.IPC Input |
| OSD: | Camera Title, Time, Video Loss, Camera Lock, Motion Detection, Recording |
| Capability: | 4-ch@8 MP(25fps)/8-ch@4MP (30fps) |
| Network | |
| Network Protocol: | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, Ipv6, Bonjour, iSCSI |
| Open Protocol: | ONVIF-S&G Support |
| Users: | 128 User |
| Storage | |
| Internal HDD: | 1 SATA Ports for 8 HDD |
| Capacity: | Up to 8TB Capacity for Each HDD |
| Interface | |
| Network Interface: | 1, RJ-45 10/100/1000 Mbps Self-Adaptive Ethernet Interface |
| Serial Interface: | RS-232; RS-485; Keyboard |
| USB Interface: | Front Panel: 1×USB 2.0; Rear Panel: 1×USB 3.0 |
| Alarm IN/Out | 2/2 |
| General Specification | |
| Power Supply: | DC 12V/1.5 A |
| Max Power: | 200W |
| Power consumption: | ≤ 30 W |
| Working Temperature: | -10 ～ 50 ℃，10% ～ 90% humidity |
| Working Humidity: | 10% to 90% |
| Chassis: | 2U Chassis with 19” Rack-Mounted |
| Working Environment: | -10̊C~+55̊C/10%~90 %RH |
| Certificate: | CE, FCC, ROHS |
| Country of Origin: | India |
