Description
Specification |
|
|---|---|
| Network Ports: | 8: 10/100Mbps PoE RJ45 port (Port 1~Port 8) 2: 10/100/1000Mbps Non-PoE RJ45 port (Port 9 ~ Port 10) Uplink |
| Standard Network Protocols: | IEEE 802.3 10BASE-T Ethernet (twisted-pair copper) IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper) IEEE 802.3u 100BASE-FX 100 Mbps over fiber optic IEEE 802.3ab 1000BASE-T Gigabit Ethernet (twisted- pair copper) IEEE 802.3z 1000BASE-X 1 Gbps over fiber optic IEEE 802.3az Energy Efficient Ethernet (EEE) IEEE 802.3x Flow Control IEEE 802.3af/at compliance (for PoE ports on PoE models) |
| Transfer Rate: | 100Mbps Full Duplex, 10 or 100Mbps Half Duplex Network Interface: 10BASE-T or 100BASE-TX Ethernet RJ-45 port |
| PoE Output: | 15.4W/30W IEEE802.3af/at |
| PoE Type: | End-Span |
| MAC address Table: | 8K |
| Switching Capacity: | 24GBPS |
| Packet Forwarding Rate: | 100Mbps:14880pps / 1000Mbps:14800pps |
| Forwarding Mode: | Store‐ and‐ Forward Switching |
| Transmission Distance: | 200~250M |
| Transmission Method: | Store and Froward |
| Packet Buffer Memory: | 4K |
| PoE Ports: | 1 To 8 |
| Jumbo Frame: | 10240 Bytes |
| Power Pin: | 1/2(+), 3/6(-) |
| Performance : |
Bandwidth: 5.6Gbps (No Block) Frames Filter and Transfer Rate: 10M Port Maximum 14,800pps 100M Port |
| Maximum 148,800pps | |
| LEDs Indicator: | Power, LINK/ACT, PoE |
| Operating Temperature: | 0 °C to 45 °C |
| Storage Temperature: | ‐ 20 ° ~ 90 ° C |
| Working Humidity: | 10% to 90% RH Non‐ Condensing |
| Storage Humidity: | 5% to 90% RH Non‐ Condensing |
| Power Supply | AC 110~265V 50/60HZ |
| Power Source: | 96W Single Port Maximum Output Power: 30W |
| Certification: | CE, FCC, ROHS |
| Country of Origin: | India |
