Specification
Ports
| Type of Switch: | Unmanaged |
| Technology: | PoE |
| PoE Ports: | PoE (1~16): 10/100/1000 Mbps PoE Ports (RJ45) Uplink: (2): 10/100/1000 MBPS Uplink Ports |
Power Over Ehternet
| PoE Standard: | IEEE 802.3i 10BASE-T IEEE 802.3u 100BASE-TX/IEEE 802.3ab 1000 Base-T IEEE 802.3xFlowControl IEEE 802.3af/at/bt Power over Ethernet |
| Management Interface: | RJ45 Serial Port (16 numbers) Out of Band, Ethernet in Band |
| CPU Memory: |
256 MB |
| Working Mode: | Extend On: 250m, 10M, CAT 5e Extend Off: 100m |
Standard
| Network Protocol: | IEEE802.3, Full duplex flow control and back pressure half duplex flow control |
| Network Latency: | (10 to 100Mbps): ≤16μs (use the 64byte package size) |
| Frame Filter & Transmission Rate: | 802.lX, the most for 10Mbps port, 148800pps the most for 100Mbps port, 1488000pps the most for 1000Mbps port |
Performance
| Performance: | Network Latency (10/100Mbps) |
| MACs Address: | 2K |
| Switching Capacity: | 80 Gbps |
| High Priority: | LED indicators for indicating working status and troubleshooting, loop detection and loop prevention |
| Transmission Medium: | Ethernet: CT3, UTP/STP cable, fast Ethernet: cat5 |
| Transmission Rate: | 2000 Mbps Full Duplex, 10/10/1000Mbps Half Duplex |
| Transmission Distance: | 100Mbps/10Mbps up to 250M |
| PoE Watchdog: | Port 1~16 |
| Gigabyte Ethernet: | Cat 6 UTP cable |
| Bandwidth: | 12.8Gbps |
| Forwarding Rate: | 1.34 Mbps/Port Loop gourd |
| Power Supply: | AC/DC, Internal, 25W DC |
| Power Output: | PoE 1~14 Port: 1/2 (+52V), 3/6(GND) PoE 15~16 Port:1245(+53V), 3678(GND) compatible 1/2(+52V), 3/6(GND)≤60W |
| Flow Control: | IEEE802.3x Full Duplex |
| Back Plane: | 16gbps |
| Operating Temperature: | -10°C~55°C |
| Operating Humidity: | 10(10-90) % Rh Non-condensing |
| Storage Temperature: | -40°~85°C |
| Max Port Power: | 30W |
| Lightning Protection: | 6KV |
| ESD Protection: | 8KV |
| Power Supply: | 100 to 240 VAC 50/60Hz |
| PoE Power Budget: | 125W |
| Max. Power Consumption: | 150W |
| Rack Mount: | Yes, 1U |
| Storage Humidity: | (5-90) % RH non-Condensing |
| Casing: | Metal |
| Country of Origin: | India |
| Certificate: | CE, FC, ROHS |
