EW-LIULD48

EW-LIULD48

EWIT LIU 1U drawer-type Fiber Rack Mount features an advanced engineering design with superior aesthetics. It is constructed from specially treated ferrous metal and finished with a black matte powder coating. This rackmount facilitates the termination of optical cables either from the central office or within the premises. The splice tray allows for the fusion splicing of optical fiber cables between the outside plant and pigtails. Additionally, all neatly arranged within cable management rings that ensure effective EW-LIULD48 strain relief through proper cable routing.

Key Features

Suitable to mount in standard 1U 19 inch rack.
Made of CRCA Steel material with black powder coating.
Drawer type for ease in maintenance.
Assembled with Adapters, Pigtails with splicing arrangement in splice tray.
Three types of cable entry & Three types of cable exit holes for different size cables through cable glands, covered with rubber cable grommets/covers.
Ease in splicing of 48 fibers in each fiber splicing trays.
Suitable for 48 LC Duplex.
Cable management rings are used to ensure flexibility of pigtails and excess fibers.
Comprehensive Accessory kits for cable entry and fiber management.

Technical Specifications

Specification	Details
Adapter Capacity	48 LC Duplex
Adapter Panels	Fixed on drawer base
Splice Tray	1no. for 48 fibers
Pigtails	48 LC
Dimensions	485 x 220 x 44.3 mm (Length x Width x Height)
SM Connectors	200 cycles, blue
Base Material	Cold Rolled Steel with Black Powder Coating
Splice Tray Material	ABS Plastic (220 x 90 x 15 mm) (Length x Width x Height)
Maximum Fiber Count	48 Fiber (SC Simplex),
Fusion Capacity	48 Fiber maximum per splice tray
Storage Temp.	-20 °C to +70° C
Installation Temp.	-20 °C to +70° C
Operating Temp.	-20 °C to +70° C
Certifications	ANSI/TIA 568-C.3 Comply as per ISO/IEC 11801 RoHS Compliant: Directive 2002/95/EC
Accessories	Cable management rings, Splice rods, Blanking clips, Velcro ties, Cable ties, Cable inlet/outlet hole covers, M6 x 16 screws.
