Product feature:
1.Adopt high performance 1/2.8” CMOS;
2.Adopt high performance imported dot matrix large glass lamps and imported high-speed glass lamp light, to ensure the IR distance 60m; product life can reach 30,000 hours;
3.Intelligent infrared control technology can automatically control the infrared light according to the environment. Under the premise of ensuring monitoring results, it can effectively enhance the infrared lamp’s life and ensure the product stability;
4.Constant current circuit design, to ensure stable operation of the infrared light. It won’t reduce the infrared lamp’s life which caused by the changing of the power supply;
5.Efficient cooling structure, using physical means heat, which can effectively reduce the temperature of the inside dome camera, to prevent the inner to be fogging, and to ensure the machine’s stability.
Technical Parameter: | |
---|---|
Model No. | SMT-AR10X-200 |
Image sensor | 1/2.8″ CMOS |
Signal model | PAL/NTSC |
Horizontal resolution | 1080P |
Effective pixel | 1920(H)ⅹ1080(V) |
Minimum illumination | Color:0.01Lux B/W:0.001Lux |
S/N radio | >50dB |
Backlight compensation | On/Off |
White balance | Auto |
Electronic shutter | PAL:1/50~1/10000s NTSC:1/60~1/12000s |
Focus length | 2.8-12mm/ 5~50mm |
Optical focus | 4X / 10X |
Focus system | Auto/Manual/Auto zoom |
Presets | 255pcs |
Patrol track | 4 groups,each group record 3min. |
Cruise track | 4 groups, each group for 16 presets |
IR distance | 60m |
Horizontal range | 255°continuous rotation |
Vertical range | -65°-0° |
Manual call speed | 0.01°-180°/s |
Protocol | PELCO D,PELCO P |
Presets call speed | Max. 60°/s |
synchronization system | Inner synchronization / power supply synchronization |
IR life | 30000 hours |
Support | AB preset scan, patrol scan, idle function, focus zoom, timer function, subject of dome camera |
IR light angle | Infrared zoom matching technology |
IR light power | Auto |
IR system | Auto/Color/Black and white |
Cooling structure | Dustproof structure outside the circle |
Fan control | ICR |
Menu | Chinese/English |
Power supply | DC12V/2A |
Protection level | IP66 |
Work temperature | -35℃~+65℃ |
