Product feature:
- Adopt in 1/2.5″ SONY Low Illumination CMOS Sensor,support Onvif.
2. H.264/H.265 video compression,2.0MP/4.0MP/5.0MP resolution.
3.Support AF zoom lens,Build-in IR-CUT,support 24pcs SMD LED,30m IR distance.
4. Support dual-stream•Support 32K ~ 8M adjustable, frame rate 1-30 frames / sec adjustable.
5.Support WEB configuration,motion detention,TF card slot/POE/ Audio optional function.
| Technical Parameter: | ||||
|---|---|---|---|---|
| Model | SMT-NRK24-800 | |||
| Imaging sensor | 1/2.5” Sony CMOS sensor | |||
| Chip | IMX274+HI3519 | |||
| Lens | 8.0MP HD 3.6-11mm MZ AF Lens | |||
| Signal system | PAL / NTSC adjustable | |||
| Min. illumination | 0.01Lux @ F1.2 (Color) (0 Lux IR LED On) | |||
| Main steam | 8.0MP,3840*2160&30fps | |||
| Deputy stream | 5.0MP,2560*1920&fps;2048*1536&30fps | |||
| Bit Rate | Support 32k-8m adjustable,1-30 fps frame rate adjustable (CBR/VBR) | |||
| Image compression | H264/H264+,Baseline/Main Profile/High Profile；H.265/H.265+ Main Profile；MJPEG | |||
| Electronic shutter | 1/25s~1/10000s; automatic | |||
| White balance | Auto | |||
| DNR | 3D-DNR | |||
| SNR | ≥50dB | |||
| DWDR | Support | |||
| Privacy masking | support | |||
| IR LED | 24pcs SMD LED | |||
| IR distance | 30m | |||
| Image adjustment | Through IE can adjust Saturation, brightness, contrast, sharpness | |||
| Network protocol | TCP/IP、UDP、RTP、RTSP、RTCP、HTTP、DNS、DDNS、DHCP、FTP、NTP、PPPOE、SMTP、UPNP | |||
| Intelligent alarm | Motion detection | |||
| Optional functions | POE / Audio / TF card slot | |||
| Mobile App | Support iPhone、iPad、Android | |||
| Network interface | One RJ45 Ethernet interface，10M/100M self-adaption | |||
| Work environment | -35℃ ~ 60℃, humidity is less than 95% (no condensation) | |||
| Power supply | DC12V/2A,<3W | |||
| Waterproof | IP66 | |||
| Size | 120(W) x 102(H)mm | |||
| Weight | 400g | |||
