Specifications
| Display Size | 19 |
| Display TYPE | LCD |
| Back Light Life(MTBF) | 70000 hours or higher |
| Max. Resolution | 1024 (W) x 768 (H) |
| Brightness (c d /m 2) | 450 |
| Contrast Ratio | 800:1 |
| LCD Colour | 16.2M |
| Touch screen and controller | 5wire resistive single touch Window/ Pen mount 6000(Anti- glare Surface)10-point Projected capacitive touch Window 6H/EETI EXC3188 (Anti UV, Anti- glare Surface) |
| I/O Ports | I*VGA (DB-15) l*HDMI1* Display Port 1.1 I*USB 2.0(touch) 1*RS-232(reserved for resistive touch ATO) 1*Lockable 9V-36V DC jack 1*9V-36V terminal block |
| Mounting Option | 19″ Rack mount Kit |
| Power Adapter | 60W; Vin: 90V-264V AC; V out: 12VDC |
| Power input | 9V-36V DC |
| Power Consumption | 9V @ 1.6A 36V @ 0.4A |
| Operating Temperature | -20°C TO —60°C (with air flow) |
| Physical Dimensions (mm) | |
| Dimensions | 303*378.5*43.2 |
| Cut-Out Dimension | 285.6*361.1 |
| Weight(kg) | 3.5/5.5 |
| IP Level | IP65 Compliant |
| Warranty | one year warranty plus 2 years post warranty |
