| Feature | Details |
| Processor: | Industrial Grade Embedded Processor |
| IP Camera Input: | 32 Channel |
| Operating System: | Embedded LINUX |
| Two-way Talk: | 1 channel Input, 1 channel Output, RCA |
| Audio: | 2-Way Radio; Codec Support G-711U, G-711A, G726. |
| User Interface: | Web, Local GUI |
| Performance By Camera: | 8 Channel |
| Performance By Face Detection: | 4 Channels |
| AI Search by Camera: | 8 Channel |
| Face Attributes: | Search for pictures by channel, time and event type |
| AI Search by Face Detection: | 6 attributes: Gender; age group (6); glasses; expressions (8); mouth mask; beard |
| Video Output: | VGA: 1920x1080p/60Hz, 1920x1080p/50Hz, 1600×1200/60Hz, 1280×1024/60Hz, 1820×720/60Hz, 1024×768/60Hz,
HDMI: 4K (3840×2160)/30Hz, 1920x1080p /60Hz, 1920x1080p/ 50Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz |
| Performance By Camera SMD: | 12 Channel |
| AI Search by SDM Camera: | Search by target classification (human, vehicle) |
| Video Recording: | 384Mbps |
| Video Display Split: | 1/4/5/6/7/8/9/10/13/16/20/25/32 |
| Third Party Camera Access: | ONVIF; RTSP |
| Network Bandwidth: | Access: 160Mbps, Storage: 128Mbps, Forward: 48Mbps |
| Recording Resolution: | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/
2CIF/CIF/QCIF |
| Compression: | Smart H.265+/H.265/Smart H.264+/H.264/MJPEG |
| OSD: | Camera Title, Time, Camera Lock, Motion Detection, Recording |
| Trigger Events: | Recording, PTZ, Tour, Alarm Out, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips |
| Motion Detection: | MD Zones: 396(22×18) |
| Video Loss/Camera Blank: | Support |
| Alarm Input/Output: | In:8Ch/Out: 2Ch |
| General Alarm: | Motion detection; privacy masking; video loss; local alarm; PIR alarm; IPC alarm |
| Anomaly Alarm: | Camera offline; storage error; disk full; IP conflict; MAC conflict; login lock; cyber security exception |
| Intelligent Alarm: | Face detection; face recognition; perimeter protection (intrusion and tripwire); IVS; People Counting, Heat Map, SMD |
| Alarm Linkage: | Record; snapshot; buzzer; log; preset; email; tour |
| Smart Phone: | iPone, iPad, Android |
| Smart Phone: | iPhone, iPad, Android Phone |
| Hard Disk: | 2 SATA III ports, up to 10TB Each, 1 eSATA Port |
| Array Type: | Hot Swappable HDD Interface with Raid0, Raid1, Raid5, Raid6, Raid10 |
| Disk Group and Quota: | Support as per Video Channel |
| Bit Rate: | 64Kbps ~ 10Mbps Per Channel |
| Decoding Capability: | 1-channel: 12MP@30fps; 1-channel 8MP@30fps; 2-channel 5MP@30fps;3- channel 4MP@30fps; 6-channel 1080p@30fps |
| Decoding Format: | H.265/H.265+/H.264/H.264+ |
| Audio Compression: | PCM: G.711A; G.711U; G.726; AAC |
| RCA: IN/Out: | 1/1 |
| Recording Mode: | Manual, Schedule (Regular/ Continuous), Motion Detection, Line Crossing, Perimeter Intrusion |
| Intelligent Video: | Support Motion Detection, Camera Tempering Detection, Perimeter Intrusion Detection |
| Search Mode: | Time, Calendar, Channel Search, Event Search, (ANR, Regular Video, Motion Detection Video, Alarm Video, Intelligent |
| Sync Playback: | 1/4/9/16 |
| Encryption: | Support Encrypted Recording from IP Camera to NVR |
|
Playback Function: |
Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Backup Selection, Digital Zoom |
| Playback Mode: | Instant Playback, Local Video, Local Image, External File Playback |
| Smart Features: | MD, Tripwire, Intrusion Detection, Video Loss, People Counting, Face Detection, Face Recognition, ANPR, AI |
| Backup Location: | Local, Network, IPSAN, NAS |
| Backup Mode: | Flash Drive, External USB Storage/Hard Disk, NAS. |
| Interface Ports: | 2 USB Ports (1 Rear USB 3.0, 1 Front USB 2.0), 1 RS485, 1 RS232 |
| Max User Access: | 128 Users |
| Record Interval: | 1~120 min (default: 60 min), Pre-record: 1~60 sec, post-record: 1~60 sec |
| Ethernet: | 1 RJ-45 port (10/100M/1000Mbps) Independent or Joint Working |
|
Protocols: |
HTTP; HTTPS; TCP/IP; IPv4; IPv6; RTSP; UDP; NTP; DHCP; DNS;
SMTP; UPnP; IP Filter; DDNS; Alarm Server; IP Search; RTSP; Auto Registration; ONVIF (profile T; profile S; profile G); CGI; SDK |
| Browser: | Firefox Version 52.0, Chrome Version 45.0, Edge Version 79.0 |
| Power Supply: | Single, AC110V ~ 240V, 50 ~ 60 Hz, 12VDC, 3.33A |
| Power Consumption: | <10W Without HDD |
| Operating Temperature: | 0°C~65°C |
| Working Temp: | -10 ~+65°C / 10~90%RH / 86~106kpa |
| Operating Altitude: | 3000M |
| Mounting: | 2U Rack Mountable with Rack Mounting Bracket |
| Casing: | Metal |
| Weight: | 1.8Kg Approx |
| Certification: | BIS, CE, FCC, ROHS, GDPR |
| Country of Origin: | India |
