EW-IP5030B
With features of simple installation, easy operation, and high performance-cost ratio, This Series camera is applicable to small and medium-sized scenes, such as homes/residences, small-sized retail stores, and other small and medium-sized enterprises. This product uses the latest PoE technology to troubleshoot the occurrence of any issues in the system making it easier to use. With the help of this technology, your camera now only consumes energy directly from the power supply and doesn’t require any mid-way switches. Regions of Interest (ROI) is a user defined feature that allows the operator to monitor specific areas of a scene while still maintaining overall situational awareness of less important areas.
- 1/2.8”Progressive Scan CMOS
- 2560×1920@25/30fps, MJPEG up to 1920×1080@30 fps
- 8/3.6/6/8/12mm Fixed Lenses
- Color:001 Lux @ (F1.2, AGC On)
- 265,H.265+, H.264, H.264+
- 120dB WDR
- 3DDNR
- IRRange up to 30 Meter
Description
| Camera | |
|---|---|
| Image Sensor: | 1/2.8” Progressive Scan CMOS Image Sensor (0.9407CM) |
| Scanning System: | Progressive |
| Min. Illumination: |
Color: 0.001 Lux @ (F1.2, AGC On) B/W: 0.014 Lux @ (F1.4, AGC On) 0 Lux with IR On |
| Effective Pixels: | 2560(H) x 1920(V) |
| Shutter Time: | 1/5s~1/100000s |
| Slow Shutter: | Yes |
| P-IRIS | Yes |
| DNR: | 3D DNR |
| Max. Image Resolution: | 5 Mega Pixel (2560×1920) @ 20fps/30fps |
| Day& Night: | IR Cut Filter. |
| WDR: | DWDR 120db |
| BLC/GC/SI: | Auto/Manual |
| Auto Gain Control: | Auto/Manual |
| NR: | 3D DNR |
| S/N Ratio: | >58db |
| White Balance: | Auto/Manual/Natural/Street Lamp/Outdoor/Regional |
| Back Light Compensation: | BLC/HLC/WDR (120dB) |
| Angle Adjustment: | Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° |
| Camera Lens | |
| Focal Length: | 3.6MM (2.8/4/6MM Optional) |
| Lens Type: | Fixed Focal |
| Mount Type: | M12 |
| Aperture Type: | Fixed |
| Max Aperture: | F2.0 |
| IRIS Type: | Fixed |
| Field of View: | H: 107.6°, V: 57°, D: 127.62° |
| Focus: | Auto, Semi-Auto, Manual |
| Digital Zoom: | 16X |
| Clouse Focus Distance: | 2.8MM: 0.8M, 3.6MM: 1.3M |
| IR | |
| IR Range: | Up to 70 Meter |
| Wavelength: | 850nm |
| Sharpness | |
| HLC: | 50Hz:25fps CIF (352×288) 60Hz:30fps CIF (352×240) |
| BLC: | Support 5 Zone |
| OSD: | 8 OSD |
| ROI: | 4 Fixed Region |
| Defog: | Support |
| Compression | |
| Video Compression: | Main Stream: H.265/H.264/H.265+/H.264+ Sub Stream: H.265/H.264/MJPEG Third Stream: H.265/H.264 Fourth Stream: H.265/H.264/MJPEG |
| H.264 Type: | Baseline Profile/Main Profile/High Profile |
| H.264+: | Main Stream Supports |
| H.265 Type: | Main Profile |
| H.265+: | Main stream supports |
| Video Bit Rate: | 128Kbps~16Mbps |
| Bit Rate Control: | CBR/VBR |
| Audio Compression: | G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3 |
| Audio Bit Rate: | 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps (G.726)/ 32-192Kbps(MP2L2)/32Kbps(PCM) |
