Description
| BASIC SPECIFICATIONS | |
|---|---|
|
Cate 6 Patch Cord Conforming to ANSI/TIA/EIA-568 C.2 or ISO/IEC:11801 latest |
Yes |
|
Patch Cord Type: Category 6 Unshielded/Unshielded Twisted Pair or Category 6 Foiled/Unshielded Twisted Pair |
CAT6 UTP |
| Type: | LSZH 1000Base T Transmission |
| Patch Cord Colour | Blue/Red/Grey/Green/Yellow |
| Conductor Diameter | 24 to 26 AWG |
| Length of Patch Cord (Mtrs) | 1/2/3/5/10/15/20 etc. |
|
Applications: 10BASE-T, 100BASE-TX Fast Ethernet, 1000BASE-T (IEEE802.3), 100VG-AnyLAN (IEEE802.12), 250 MHz Broadband Video, Voice, 11, ISDN, 155 / 622 Mbps ATM, Power over Ethernet (POE, POE+, 4 PPOE) |
Yes |
| Termination Type / Connection Type | Insulation Piercing Connection (IPC) |
| Modular Plug | RJ45 |
| Plug Insertion Durability | ≥ 750 mating cycles” |
| Conductor Material | Stranded copper |
| Conductor Insulation Material | Polyethylene |
| Cable Jacket Material | Fire retardant PVC |
| Storage Temperature Range | -20 deg. C to +60 deg. C |
| Operating Temperature Range | -20 deg. C to +60 deg. C |
| UL Marking on Cable | Yes |
