| Specification | |
|---|---|
| Type of Switch | Managed |
| Technology | PoE |
| Number of 1G Copper Ports | 24 |
| Number of 10G Copper Ports | 0 |
| Number of 1 G SFP Port (Uplink) | 0 |
| Number of 10 G SFP+ Port (Uplink) | 4 |
| Multi-Gigabit Support | No |
| Redundant Power supply ( from day one) | Available |
| Console Port | Available |
| Switching Capacity-Non Blocking (Gbps | 128 |
| Throughput (MPPS) | 95.23 |
| Operating System | Available |
| Dedicated Stacking Port/Slot ( from day one) | Available |
| Stacking Bandwidth (Gbps) | 80 |
| Basic Layer-3 Protocol | Static routing ,Routed Access (RIP, EIGRP Stub, OSPF – Upto 1000 routes), PIM, PBR, CDP, Netflow ETC |
| Security Feature | 802.1X, SPAN,BPDU Guard, Multidom.Auth., ACL, Port-based ACLs, Kerberos, TACACS+&RADIUS auth.,STRG, MACsec-128, FHS |
| Management Protocol | Telnet, SSH, SNMP (v1, 2c and 3), NTP, TFTP.ETC |
| QoS | Up to 8 egress queues&2 thresholds per port,SRR scheduling & WTD congestion avoidance, 802.1p CoS ETC. |
| Operating Temperature Range (Degree C) | -5 to 45 |
| Operating Humidity (RH)(%) | 5 to 90 |
| IPv6 Ready from day one and dully certified | Yes |
| PoE Power Budget ( Watt ) | 370 |
| On Site OEM Warranty | 5 Year |
