| Specifications | |
|---|---|
| Maximum Number of Access/Downlink Ports | 24 |
| Type of Switch | Non PoE |
| Number of 10/100/1000 Base-T Ports | 24 |
| Number of Multi-Gigabit Ports | 0 |
| Number of 1 G Base T Ports (Uplink) | 0 |
| Number of 1 G SFP / Base X Port (Uplink) | 4 |
| Number of 10 G Base T Port (Uplink) | 0 |
| Number of 10 G SFP+ Port (Uplink) | 0 |
| Number of 40 G QSFP+ Port (Uplink) | 0 |
| Number of 100 G QSFP 28 Port (Uplink) | 0 |
| Management Port (RJ 45/RS 232/USB) | Yes |
| RAM (MB) | 2048 |
| Flash Memory (MB) | 4096 |
| 9K MTU Supported (Minimum) | Yes |
| Console Port | Yes |
| Redundant Power supply | Yes |
| Redundant Power Supply Type | Internal |
| Redundant Power Supply (Hot Swappable) | Yes |
| Redundant Fan | Yes |
| Redundant Fan (Hot Swappable) | Yes |
| Number of Open slot for additional Interface Card | 0 |
| Operating System | Yes |
| Dedicated Stacking | Yes |
| Stacking Bandwidth (Gbps) | 80 |
| Switching Capacity / Forwarding Bandwidth (Non Blocking / Line Rate /Wired Speed) 2x (Numbers of access ports + Number of Uplink Ports) (Gbps) | 208 |
| Throughtput / Forwarding Performance (MPPS) | 154 |
| Layer 2 Protocols | 802.1Q VLAN,LAG,LACP, STP,MSTP,RSTP, IEEE 802.3x,VLAN |
| Number of VLAN Supported | 4000 |
| Number of VLAN IDs Supported | 4000 |
| Number of IPV4 Routes | 20000 |
| Number of IPV6 Routes | 10000 |
| Number of Mac Address Supported (k) | 16 |
| Basic Layer-3 Protocol from day 1 | Static Routing,RIPv1,RI Pv2, BGP,OSPFv2,OS |
| PFv3 | YES |
| Advance Layer-3 Protocol from day 1 | OSPFv2,OSPFv3, BGP,BGP4 ,PIM-SM,PIM- SSM,PIM-DM |
| Premium Layer-3 Protocol from day 1 | BGP,BGP4,PIM- SM,PIM- SSM,PIM- DM,VRRP |
| Security Feature | RA guard, DHCPSnooping, Dynamic ARP Inspection, ACL,802.1x, RADIUS/ TACACS, Port Security, |
| BPDU | Guard, IGMP snooping |
| Management Protocol | GUI,CLI,Tel net,TFTP,S NMPv1, SNMPv2/ V2C,SNMPv 3,NTP,RMON, SSHv2,Single IP Managemen t, Hitless patch upgrades, DLDP/UDL D |
| QoS | 802.1p,SP,Queue s per port, CAR, WRED/WTD,Sow,SNTP,Shapincg, Policing/ Rate Limiting, Strict Priority Queueing or Low Latency Queueing |
| PoE Power Budget (Watt) | 0 |
| Dimension / Form Factor (RU) | 1 |
| Certification | NDPP, RoHS |
| MTBF (Year) | 7 |
| Minimum Operating Temperature (Degree C) | 0 Degree C |
| Maximum Operating Temperature (Degree C) | 60 |
| Minimum Operating Humidity (%RH) | 5 |
| Maximum Operating Humidity (%RH) | 95 |
| IPv6 Ready from day 1 | Yes |
| On Site OEM Warranty (Year) | 3 |
EW-24L3NPO4S
