| Specification | |
|---|---|
| Pipe Configuration | Two Pipe |
| Condenser Fan Number per unit | 1 |
| Number of Phases | Single |
| Types of Variable Refrigerant Systems | Cooling Only |
| Types of Condenser Fan | Propeller Fan |
| Technical Specifications | |
|---|---|
| COP (Coefficient of Performance), kW/kW | 3.8-3.9 |
| Number of Modules | 1 |
| Capacity of Cooling,kW | 22-25 |
| Input power of Heating,kW | 6-7 |
| Capacity Range,HP | 4 horsepower |
| Rated Capacity (Ton) | 6 |
| Refrigerant Charge Volume | 5.5 kilogram |
| Fuse Current(Rating) | 16 Ampère |
| EER (Energy Efficiency Ratio), kW/kW | 3.3-3.4 |
| Maximum number of indoor unit | 13 |
| Input power of Cooling,kW | 5-7 |
| Capacity of Heating,kW | 25-30 |
| Frequency,Hz | 60 Hertz |
| Rated Voltage,volts | 220-240 |
| Maximum Connectable Indoor Unit | 15 |
| Dimension | |
|---|---|
| Height,mm | 1500 millimeter |
| Width,mm | 900 millimeter |
| Depth,mm | 500 millimeter |
| Net Weight,Kgs | 200 kilogram |
