| BASIC SPECIFICTIONS | |
|---|---|
| Type of Switch | UNMANAGED |
| Technology | NON POE |
| Number of 1G Copper Ports | 24 |
| Number of 10G Copper Ports | 0 |
| Number of 1 G SFP Port (Uplink) | 2 |
| Number of 10 G SFP+ Port (Uplink) | 0 |
| Multi-Gigabit Support | NO |
| Redundant Power supply ( from day one) | Not Available |
| Console Port | Available |
| Switching Capacity-Non Blocking (Gbps) | 50 |
| Throughput (MPPS) | 14.50 |
| Operating System | Available |
| Dedicated Stacking Port/Slot ( from day one) | Not Available |
| Stacking Bandwidth (Gbps) | 50 |
| Basic Layer-3 Protocol | Static Routing 32 static entries |
| Security Feature | ACL 802.1x IEEE 802.1Q VLAN support |
| Management Protocol | GUI Web Managed SNMPv1 |
| QoS | 802.1P, 8 Priority Queues per Port, |
| Operating Temperature Range (Degree C) | 0°C to 70°C |
| Operating Humidity (RH)(%) | 10% To 90% |
| IPv6 Ready from day one and dully certified | Yes |
| PoE Power Budget ( Watt ) | 240 |
| Make | ewit |
| Model No. | EW-24UMNP02S123W |
24 Unm L2 datasheet 01
