Function Characteristic:
1.Adopt high performance 1/2.8″ CMOS.
2.Support dual stream compression technology.
3.Using imported dot matrix large glass lamps and imported high-speed glass lamp light, to ensure the IR distance 60 m; product life can reach 30,000 hours.
4.Intelligent infrared control technology can automatically control the infrared light according to the environment. Under the premise of ensuring monitoring results, it can effectively enhance the infrared lamp’s life and ensure the product stability.
5.Constant current circuit design, to ensure stable operation of the infrared light. Andit won’t reduce the infrared lamps’ life which caused by the changing of the power supply.
6.Efficient cooling structure, using physical means heat, which can effectively reduce the temperature of the inside dome camera, to prevent the inner to be fogging, and to ensure the machine’s stability.
Parameter: | |
---|---|
Model No. | SMT-NR10X-200 |
Image sensor | 1/2.8″ CMOS |
Chip | IMX323+HI3516C-V300 |
Horizontal resolution | 1080P |
Optical focus | 4X/10X |
Focus length | 2.8-12mm/5-50mm |
Minimum illumination | 0.01Lux @(F1.6,AGC ON) ,0 Lux with IR |
IR distance | 60M |
Video compression | H.264 |
Signal model | 50HZ:25fps(1920 X 1080) 60HZ:30fps(1920 X 1080) |
Video bit rate | 32kbps-16Mbps |
Day and Night | ICR |
3D Control | Support |
Electronic shutter | 1/25s ~ 1/100000s |
D-WDR | Support |
DNR | 2D/3D-DNR |
Image direction | Mirror/ Flip |
Privacy zone | Support |
Mobile detection | Support |
Horizontal range | 0°~260° |
Vertical range | -5°~60° |
Horizontal speed | 0.5°~12°/ s |
Vertical speed | 0.5°~12°/ s |
Presets | 255 |
Cruise track | 8 groups, each group for 16 presets |
Patrol track | 4 groups, each group record 3 mins |
NETWORK | RJ45 |
TF CARD | Max 64G(Matching) |
Audio I/O | 1 input,1 output(Matching) |
Audio compression | G.711A |
Alarm I/O | 1 input,1 output(Matching) |
Network protocol | TCP/IP、UDP、RTP、RTSP、RTCP、HTTP、DNS、DDNS、DHCP、FTP、NTP、PPPOE、SMTP、UPNP |
ONVIF | Support |
protection level | IP66 |
Bracket | Wall mounted |
dimension | 153mm×93mm×130mm(L×W×H) |
Weight | 920g |
Power | DC12V/2A |
Work temperature | -30℃~60℃ |
