Application:
Can be widely used in the need for a wide range of high-definition quality monitoring sites, the use of scenarios: warehouse,underground.parking, access,staircase, supermarkets, Internet cafes, etc.
Product Overview:
- 5.0MP 1/2.8’’ Low illumination 335CMOS, 4X optical zoom;
- Precision worm gear driven, keen responsive,smoothly operation, the precision deviation less than 0.1 degree;
- Support lightning protection,surge protection and voltage transient protection;
- Protection Grade:IP66;
- Support ONVIF protocol GB/T28281, seamless working with HIKVIISON, DAHUA,XM and other platform;
- Metal plus plastic case, support H.265 / H.264/ MGPEG dual encoding three kind of stream.
- Support POE function customization. POE standard: 802.3at
- App in IOS and Android system: Hisee
.
Feature：
- 4PCS Infrared lights, effective IR distance up to 20m.
- 355°endless pan range and 0°- 90°tilt range no blind monitor area.
- Max. pan preset speed of 80°/s and max. tilt preset speed of 80°/s
- Pan control speed 10°~80°/s, tilt control speed 10°~80°/s
- Support 220 presets,
- SupportProportional zoom function, rotation speed can be adjusted automatically according to zoom multiple.
- Support park action, presets can invoke automatically after a defined time of inactivity
(contain the idling condition after the power supply has been turn on)
Technical Parameters:
| Model Number | SMT-NM2RU-5MP | ||
| PTZ | IR Distance | 20m | |
| Pan range and speed | Pan 0°- 355°rotate endless; speed 0-80°/s | ||
| Tilt range and speed | 0°～90°, speed 0-80°/s | ||
| Preset | 220 pcs | ||
| Park function | Support park preset | ||
| Zoom lens | Video | resolution | 5MP 2592（H）ⅹ1920（V） |
| sensor | 1/2.8” 5MP M Sony 335 CMOS | ||
| Illumination | 0.005Lux@F1.2(color mode);0.001Lux@F1.2(night mode);
0Lux(IR lights turn on ) |
||
| S/N | ≥50dB（AGC OFF） | ||
| Lens | Optical | 4x optical zoom, 2.8mm-12mm, F1.7-F3.0 | |
| Pan view angle | 113.9°(near) ~34.1°(far)° | ||
| Function | BLC | Auto/manual/indoor/outdoor/sodium lamp | |
| Exposure | Program mode/shutter mode(1/5 – 1/20,000s)/ support slow shutter | ||
| Gain control | Auto/manual | ||
| WDR range | Support DWDR, ≥73.7dB | ||
| Noise reduction | Support DNR,3DNR | ||
| Focus mode | Auto/manual | ||
| Day-night mode | Support | ||
| Number of visitor | Main stream: Three users; Sub-stream: Five users | ||
| Network protocol | TCP/IP,HTTP,NTP,IGMP,DHCP,UDP,SMTP,RTP,RTSP,
ARP,DDNS,DNS,P2P |
||
| Compatibility | Seamless working with HIKVISION, XM and so on platform.
Support many brands of NVR via ONVIF 2.4; GB28181 |
||
| Mobile remote control | Support Android & iOS system mobile to access | ||
| Video resolution | Main stream:2592*1920, 1920×1080,1280×960,1280×720 | ||
| Interface | Video interface | RJ45 network interface,support POE | |
| Power supply | DC 12V/2A | ||
| Others | Power consumption | 10W（max） | |
| Working temperate and humidity | -20℃～+60℃，≤90%RH(no frostless) | ||
| Protection grade | TVS3000V lightning protection, surge protection and voltage transient protection
weather proof (for outdoor): IP66 |
||
