WHITE LED Specifications

Model	EW-WLST-75WP
System	White LED based solar street lighting system as per MNRE Specification
PV Module	75 Wp, Crystalline Silicon Terrestrial Photovoltaic (PV) modules, Minimum efficiency 14%
Battery Voltage	12.8 V
Battery Capacity	30 Ah
Battery Type	Lithium Ferro Phosphate
Battery Enclosure	External enclosure with IP65 Protection
Light Source	White Light Emitting Diode (W-LED), 12 Watt, Total luminous flux ≥ 1500 lm, Luminous efficacy ≥ 125 lm/W
Color Temperature	5500 K to 6500 K
Electronics Efficiency	≥ 90%
Ingress Protection (IP)	IP 66 for Optical and Control gear compartment
Mechanical Components	Steel Pole as per IS:1161, Medium Class, 6 meters height
Corrosion Resistant Structure	Yes
Pole to Hold Luminaire	Yes
Warranty for Lighting System	60 months
Warranty for PV Module	25 years
PV Module Output (≥ 90%) Warranty	10 years
PV Module Output (≥ 80%) Warranty	25 years
Certifications	Type Test Report: XT030419000003162FN (dated 4/5/19), conducted by Associated, Uttar Pradesh
BIS CRS Certificates	Yes
