Description
Specifications
| Type of Switch: | Unmanaged |
| Technology: | PoE |
| Network Interface: | PoE: 4 Port 10/100/1000 Mbps SFP: 2 Port 10/100/1000 Mbps |
| Standard Network Protocols: | IEEE802.3 10BASE-T, IEEE 802.3u 100BASE—TX, ANSI/IEEE 802.3 NWay Auto-Negotiation, IEEE802.3x Flow Control, IEEE 802.3af/at standard |
| Forwarding Method: | Store-and-Forward |
| Flow Control: | Back-Pressure Flow Control in IEEE 802.3x Full Duplex |
| MAC address Table: | 1K QoS |
| Switching Capacity (Non-Blocking): | 36GBPS |
| Packet Forwarding Rate: | 10M:14,800pps, 100M: 148,800pps |
| Forwarding Mode: | Store‐and‐forward switching |
| Packet Buffer Memory: | 4K |
| Throughput (MPPS): | 14.88 |
| Transmission Distance: | Up to 200 Meters |
| Max Power Consumption: | 30W |
| PoE Budget: | 65W |
| VLAN | Supports up to 4K VLANs Simultaneously (out of 4K VLAN IDs) Port/MAC/Protocol‐based VLAN Management VLAN configuration |
| Operating Temperature: | -10°C to 40°C |
| Storage Temperature: | ‐40 ° ~ 70 ° C |
| Surge Protection: | 6KV |
| Storage Humidity: | 5% to 95% RH Non‐Condensing |
| Power Input: | 48V DC, 0.8 A Reverse Connection Protection |
| Certification: | CE, FCC, ROHS |
