Key Features
- 1/2.7” Progressive Scan CMOS
- 2592×1944@25/30 fps, 4MP 2688×1520@20 fps
- 8 To 12 mm Motorized Varifocal Lenses
- Color: 01 Lux @ (F1.2, AGC ON)
- 265, H.265+, H.264, H.264+
- 140 dB WDR
- 3D DNR
- IR Range up to 30 Meter
- Alarm I/O
Specifications
| Camera | |
|---|---|
| Image Sensor: | 1/2.7” Progressive Scan CMOS Image Sensor |
| Scanning System: | Progressive |
| Min. Illumination: |
Color: 0.005 Lux @ (F1.2, AGC On) B/W: 0.001 Lux @ (F1.2, AGC On) 0 Lux @ IR On |
| Effective Pixels: | 2592 (H) x 1944 (V) |
| Shutter Time: | 1/25s – 1/100000 sec |
| Slow Shutter: | Yes |
| P-IRIS | Yes |
| DNR: | 3D DNR |
| Max. Image Resolution: | 5 Mega Pixel (2592×1944) @ 50fps/60fps |
| Day& Night: | Yes, with IR Cut Filter. |
| Lens | |
|---|---|
| Focal Length: | 2.8~12 MM |
| Lens Type: | Motorized Varifocal Lens |
| IRIS: | Fixed |
| Mount Type: | Ø14 |
| Digital Zoom: | 16X |
| Max Aperture: | F1.6~F2.8 |
| Angle of View: | 2.8~12MM: H: 98°~34°, D: 116°~40°, V: 52°~19° |
| Closed Focus Distance: | 0.8M |
| Focus: | Auto, Semi-Auto, Manual |
| DORI: | W: 64.4M (D), 25.8M(O), 12.9M(R), 6.4M(I) T: 221.M (D), 88.6M(O), 44.3M(R), 22.1M(I) |
| Sharpness | |
|---|---|
| HLC: | 50Hz:25fps CIF (352×288) 60Hz:30fps CIF (352×240) |
| BLC: | Support |
| OSD: | 8 OSD |
| ROI: | 4 Area |
| Defog: | Support |
| Compression | |
|---|---|
| Video Compression: |
Video Compression: H.265 +/H.265/H.264 +/H.264/MPEG Audio compression: G.711-ULaw, G.711-ALaw, AAC LC, G.722 and G.726 |
| Video Bit Rate: | 128Kbps~8Mbps |
| Bit Rate Type: | CBR/VBR |
| Audio Compression: | G.711a/ G.711Mu/G.722.1/G.726/MP2L2/PCM |
| Audio Bit Rate: | 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps (G.726)/ 32-192Kbps(MP2L2)/32Kbps(PCM) |
| Image | |
|---|---|
| Resolution: | 5MP: 2592×1944; 2304×1296; 1920×1080; 720×576 |
| Video Streams: |
Main Code Stream: 5MP@1-20fps, 4MP@1-25fps, Full Frame, 2MP@1-25fps, Full Frame Sub-Code Stream: D1, VGA@1-25fps, Full Frame Third-Code Stream: CIF @1-25fps, Full Frame |
| Image Enhancement: | BLC, HLC, 3D DNR, Defog, EIS, ROI, AWB, AGC |
| Image Setting: | Brightness, Contrast, Saturation, Sharpness, Exposure, White Balance, WDR, BLC, Mirror, Flip,3D NR |
| Video Analytics: |
Audio Detection, Face Detection/Human Detection, Line Crossing Detection, Intrusion Detection, Region Entrance/ Exiting, Abandoned Object, Missing Object, People Counting, Loitering Detection, Tempering Alarm |
| Target Cropping: | Yes |
| SVC: | H.264 and H.265 Encoding |
| Network | |
|---|---|
| Event Trigger: | No SD Card, SD Card Full, SD Card Error, Network Disconnection, IP Conflict, Illegal Access, Motion Detection, Video Tampering, Intrusion, Trip Wire, Scene Changing, Audio Detection, Voltage Detection, Defocus Detection, External Alarm, SMD, Safety Exception |
| Protocols: |
IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; SNMP; ONVIF (Profile G/S/T) |
| Simultaneous View: | Up To 20 Channels |
| Users: | 20 |
| Privacy Masking: | 4 Areas |
| Mobile: | iPhone, iPad, Android |
| Security Measures: |
Password Protection, HTTPS Encryption, IEEE 802.1x port-Based Network Access Control, IP Address Filter, Basic and Digest Authentication for HTTP/HTTPS, WSSE and Digest Authentication for ONVIF |
| Compatible Integration: | ONVIF (Profile S), SDK, API Support |
| Mirror: | Yes |
| Encrypted Data Transmission: | HTTPS (SSL/TSL) |
| Web Browser: | IE8+, Chrome41.0-44, Firefox30.0-51, Safari8.0-11 |
| Bandwidth: | 32Kbps~8192Kbps |
| General Function: |
One-key Reset, Anti-Flicker, 5 Streams and up to 5 Custom Streams, Heartbeat, Password Protection, Privacy Mask, Watermark, IP Address Filter |
| Smart Feature | |
|---|---|
| Intelligent AI Feature: | Face Detection, Active Deterrence, Vehicle Detection, Trip Wire |
| Behavior Analysis: |
Line Crossing Detection, Intrusion Detection, Region Entrance Detection, Region Exiting Detection, Unattended Baggage Detection, Object Removal Detection |
| Exception Detection: | Scene Change Detection, Defocus Detection |
| Statistics: | Counting |
| Face Detection: | Yes |
| Cyber Security: |
Video Encryption, Firmware Encryption, Configuration Encryption, Digest, WSSE, Account Lockout, Security Logs, IP/MAC Filtering, Generation and Importing of X.509 Certification, Syslog, HTTPS, 802.1X, Trusted Boot, Trusted Execution, Trusted Upgrade |
| Region of Interest: |
Main Stream/Sub Stream/Third Stream/Fourth Stream/Fifth Stream: 4 Fixed Regions For Each Stream And Dynamic Face Tracking |
| General | |
|---|---|
| General Function: | Anti-flicker, Heartbeat, Mirror, Password Protection, Privacy Masks, Watermark, IP Address Filter |
| Operating Conditions: | -40 °C ~ 70 °C (-40 °F ~ 140 °F) Humidity 95% or less (non-condensing) |
| Power Supply: | PoE (802.3AT, 42.5V TO 57V), 0.5A TO 0.3A, MAX 18w |
| Power Consumption: | 12 VDC, 1.2A, MAX 7 W |
| Weather Proof: | IP 67 IK10 |
| Body Type: | Vandal Dome |
| Weight: | 350g |
| Certification: | BIS, CE, FC, ROHS |
| Country of Origin: | India |
