| Specification |
| Camera |
| Image Sensor: |
1/3″ Progressive Scan CMOS |
| Scanning System: |
Progressive |
| Min. Illumination: |
Color: 0.005 Lux @ (F1.6, 30IRE) / B/W: 0.0005 Lux @ (F1.6, 30IRE) / 0 Lux (Illuminator On) |
| Effective Pixels: |
2560 (H) × 1440 (V) |
| Shutter Time: |
Auto/Manual 1/3s – 1/100000 sec |
| Slow Shutter: |
Yes |
| P-IRIS: |
Yes |
| DNR: |
3D DNR |
| Max. Image Resolution: |
4 MP (2560×1440) @ 20/25 fps |
| Day & Night: |
IR Cut Filter (Auto) |
| WDR: |
120 dB, DWDR |
|
| Image / Video |
| Max. Resolution: |
2560 × 1440 |
| Video Streaming: |
Main Stream: 2560 × 1440 @ (1–25/30 fps); Sub Stream: 704 × 576 @ (1–25/30 fps) / 704 × 480 @ (1–30 fps) |
| Supported Resolutions: |
4MP (2560×1440), 3MP (2304×1296), 2MP (1920×1080), 1.3MP (1280×960), 720P (1280×720), D1, VGA, CIF |
| Image Enhancement: |
BLC, HLC, 3D DNR, Defog, EIS, ROI, AWB, AGC |
| Image Setting: |
Rotate Mode, Saturation, Brightness, Contrast, Sharpness, Hue; Adjustable via client software or browser |
| Image Rotation: |
0° / 180° |
| Target Cropping: |
Yes |
| SVC: |
H.264 and H.265 Encoding |
|
| Compression / Streaming |
| Video Compression: |
H.265 / H.265+ / H.264 / H.264+ / MJPEG (Main/Sub/Custom streams supported) |
| H.265 Code Type: |
Baseline / Main / High Profile |
| Bit Rate: |
CBR / VBR |
| Video Bit Rate: |
32 Kbps – 6 Mbps |
| Audio Compression: |
G.711a / G.711Mu / G.722.1 / G.726 / MP2L2 / PCM |
| Audio Bit Rate: |
64 Kbps (G.711) / 16 Kbps (G.722.1) / 16 Kbps (G.726) / 32–192 Kbps (MP2L2) / 32 Kbps (PCM) |
|
| Camera Lens |
| Focal Length: |
3.6 mm |
| Lens Type: |
Fixed Focal |
| Mount Type: |
M12 |
| Max Aperture: |
F2.0 |
| IRIS Type: |
Fixed IRIS |
| Angle of View: |
3.6 mm: H 76°, V 40°, D 92° |
| ICR: |
Auto (ICR) / Color / B/W |
| Close Focus Distance: |
3.6 mm – 1.4 m |
| Digital Zoom: |
16× |
|
| IR |
| IR Range: |
Up to 80 Meter |
| Wavelength: |
850 nm |
|
| Network |
| Abnormal Detection: |
Motion Detection, Video Tampering, Network Disconnect, IP Conflict, Illegal Login, HDD Error |
| Protocols: |
IPv4 / IPv6, HTTP, TCP, UDP, RTSP, FTP, DHCP, DNS, DDNS, QoS, NTP, UPnP, SMTP, SNMP, HTTPS |
| Simultaneous View: |
Up to 20 Channels |
| Users: |
20 |
| Privacy Masking: |
3 Areas |
| Mobile: |
iPhone, iPad, Android |
| Cyber Security: |
Configuration encryption, Digest, Security logs, HTTPS, WSSE, 802.1x, IP/MAC filtering |
| Compatible Integration: |
ONVIF (Profile S / G / T), CGI |
| SDK & API: |
Yes |
|
| Interface |
| Communication Interface: |
1 × RJ45 10M / 100M Ethernet Port |
| Audio: |
1 Input, 1 Output, Mono |
| Alarm: |
1 Input, 1 Output |
| Video Output: |
1 Vp-p composite output (75 Ω / CVBS) |
| On-board Storage: |
Support SD / Micro SD card up to 256 GB / NAS |
| Reset Button: |
Yes |
|
| Smart Features |
| Behavior Analysis: |
Line Crossing Detection, Intrusion Detection, Region Entrance/Exit Detection |
| Exception Detection: |
Scene Change Detection, Defocus Detection |
| Statistics: |
Counting |
| Face Detection: |
Yes |
| Smart Detection: |
Tripwire, Intrusion |
| Region of Interest: |
Up to 4 Fixed Regions per Stream |
|
| General |
| General Functions: |
Anti-flicker, Heartbeat, Mirror, Password Protection, Watermark, IP Filter, User Authentication |
| Operating Conditions: |
-40 °C to 60 °C; Humidity ≤ 95% (non-condensing) |
| Power Supply: |
PoE (IEEE 802.3af, 42.5V–57V) |
| Power Consumption: |
Basic: 1.4 W (12 VDC); Max: 4.2 W (PoE) |
| Casing: |
Metal / Plastic |
| Weather Proof: |
IP67, IK10 |
| Weight: |
0.45 kg |
| Certification: |
BIS, CE, FCC, ROHS, GDPR, ISO |
| Country of Origin: |
India |
|
