| Type of Switch |
Managed |
| Technology |
PoE+ |
| Number of 1G Copper Ports |
8 |
| Number of 10G Copper Ports |
0 |
| Number of 1 G SFP Port (Uplink) |
2 |
| Specification |
| Number of 10 G SFP+ Port (Uplink) |
0 |
| Multi-Gigabit Support |
No |
| Redundant Power supply ( from day one) |
Not Available |
| Console Port |
Not Available |
| Switching Capacity-Non Blocking (Gbps) |
20 |
| Throughput (MPPS) |
14.9 |
| Operating System |
Available |
| Dedicated Stacking Port/Slot ( from day one) |
Not Available |
| Stacking Bandwidth (Gbps) |
0 |
| Basic Layer-3 Protocol |
IP, ICMP, IGMP, DHCP Relay, DHCP L2 Relay, Link Aggregation, Spanning Tree Protocol, Loopback Detection, Flow Control |
| Security Feature |
ACL, VLAN, 802.1x, snooping, storm control, Smart IMPB (IP-MAC- Port binding), AAA, 802.1X, IP/IPv6-MAC Binding |
| Management Protocol |
SNMP, TELNET, RMON, SSH, Web-based GUI, Command Line Interface (CLI) through telnet, SNMPv1/v2c/v3, SNMP Trap/Inform |
| QoS |
COS, COS DSCP, IP PRECEDENCE, SP, WRR, FLOW CONTROL, 802.1p
CoS/DSCP priority, 8 priority queues, Priority Schedule Mode |
| Operating Temperature Range (Degree C) |
0–50 ℃ (32–122 ℉) |
| Operating Humidity (RH)(%) |
10–90% RH non-condensing |
| IPv6 Ready from day one and dully certified |
Yes |
| PoE Power Budget ( Watt ) |
150 |
| On Site OEM Warranty |
3 Year |
