EW-20HD02B
Key Features –
- 1/2.7” PS CMOS Image Sensor
- 20 Meter IR Range
- Low Illumination
- True Day & Night
- Wide operating
- Turbo Full HD
Description
SPECIFICATION |
|
|---|---|
| Camera | |
| Body Type: | Dome |
| Image Sensor: | 1/2.7″ Progressive Scan CMOS Image Sensor |
| Signal System: | PAL/NTSC |
| Min. Illumination: | Color: 0.02 Lux@F1.85, 30 IRE, AGC on, 0 lux with IR B/W: 0.002 Lux@F1.85, 30 IRE, AGC on, 0 lux with IR |
| Shutter Speed: | PAL: 1/25~1/100000s NTSC: 1/30~1/100000s |
| Lens: | 3.6mm Lens |
| Gain Control (AGC): | Auto/Manual |
| Lens Mount: | M12 |
| White Balance: | Auto/Manual |
| Angle of View: | H: 87.5° (103°) |
| Day& Night: | Electronic |
| Horizontal Resolution: | 2 MP |
| Digital Zoom: | 16X |
| Synchronization: | Internal Synchronization |
| Video Output: | 1Vp-p Composite Output (75Ω/BNC) |
| S/N Ratio: | 65 dB |
| WDR: | 120db |
| ICR: | Auto/Manual |
| OSD: | Multi Language |
| Video Streaming: | 2MP: 25/30fps, 720P: 25/30, 50/60fps |
| General | Video Output: | 1-Ch BNC HD Video Output/ CVBS Video Output (Switchable) |
|---|---|
| Back Light Compression: | BLC/HLC/DWDR |
| Operating Conditions: | -40 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing) |
| Power Supply: | 12 V DC±30% |
| Power Consumption: | 3W max. |
| Weather Proof: | IP66 |
| IR Range: | 24 LED (Approx 20 meters) |
| Dimension: | Φ 129 × 80.1 mm (Φ 5.08” × 3.15”) |
| Country of Origin: | India |
| Certified: | ISO, CE, FC and RoHS |
