Specification:
| Feature | Details |
|---|---|
| Type of Switch: | Managed |
| Technology: | PoE |
| Network Ports: | 8: 10/100/1000Mbps PoE RJ45 port (Port 1~Port 8) 2: 10/100/1000Mbps Uplink SFP Port |
| Standard Network Protocols: | IEEE 802.3 10BASE-T Ethernet (twisted-pair copper) IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper) IEEE 802.3u 100BASE-FX 100 Mbps over fiber optic IEEE 802.3ab 1000BASE-T Gigabit Ethernet (twisted- pair copper) IEEE 802.3z 1000BASE-X 1 Gbps over fiber optic IEEE 802.3az Energy Efficient Ethernet (EEE) IEEE 802.3x Flow Control IEEE 802.3af/at compliance (for PoE ports on PoE models) |
| Transfer Rate: | 2000 Mbps Full Duplex, 10/100/1000 Mbps Half Duplex Network Interface: 10BASE-T or 100BASE-TX Ethernet RJ-45 port |
| PoE Output: | 15.4W/30W IEEE802.3af/at |
| PoE Type: | End-Span |
| MAC address Table: | 8K |
| Switching Capacity: | 24 GBPS Non-Blocking |
| Through Put: | 14.88 Mbps |
| Packet Forwarding Rate: | 14.88 Mpps |
| Forwarding Mode: | Store-and-Forward Switching |
| Transmission Distance: | 100~150M |
| DRM Size: | 128MB |
| Flash Memory: | 32MB |
| Transmission Method: | Store and Forward |
| Packet Buffer Memory: | 4MB |
| PoE Ports: | 1 To 8 |
| Jumbo Frame: | 10240 Bytes |
| Power Pin: | 1/2(+), 3/6(-) |
| Performance: | Bandwidth: 5.6Gbps (No Block) Frames Filter and Transfer Rate: 10M Port Maximum 14,800pps 100M Port Maximum 148,800pps |
| LEDs Indicator: | Power, LINK/ACT, PoE |
| Operating Temperature: | 0 °C to 45 °C |
| Storage Temperature: | -40 ° ~ 85 °C |
| Working Humidity: | 05% to 90% RH Non-Condensing |
| Max Port Power: | 30W |
| PoE Power Budget: | 65W |
| Max. Power Consumption: | 90W |
| Surge Protection: | PoE Port with 6KV Surge Protection |
| Storage Humidity: | 5% to 90% RH Non-Condensing |
| Power Supply: | AC 100~240VAC 50/60HZ |
| Power Source: | DC48-57V Power Adapter |
| Casing: | Metal |
| Certification: | CE, FCC, ROHS |
| Country of Origin: | India |
