Function Characteristic:
1.Adopt high performance 1/2.8″ CMOS.
2.Support dual stream compression technology. Default support WIFI ,Optional function: Audio / Alarm.
3.Using imported dot matrix large glass lamps and imported high-speed glass lamp light, to ensure the IR distance 60 m; product life can reach 30,000 hours.
4.Intelligent infrared control technology can automatically control the infrared light according to the environment. Under the premise of ensuring monitoring results, it can effectively enhance the infrared lamp’s life and ensure the product stability.
5.Constant current circuit design, to ensure stable operation of the infrared light. And it won’t reduce the infrared lamps’ life which caused by the changing of the power supply.
6.Efficient cooling structure, using physical means heat, which can effectively reduce the temperature of the inside dome camera, to prevent the inner to be fogging, and to ensure the machine’s stability.
| Technical Parameter: | |
|---|---|
| Model | SMT-NR10X-200 |
| Signal model | PAL/NTSC |
| Image sensor | 1/2.8″ SONY CMOS sensor |
| Chip | IMX323+HI3516C-V200 |
| Effective pixel | 1920(H)x1080(V) |
| Horizontal resolution | 1080P |
| Minimum illumination | Color:0.01Lux,B/W:0.001Lux |
| S/N radio | >60dB |
| Backlight compensation | On/off |
| White balance | Auto |
| Electronic shutter | PAL:1/25～1/100000s NTSC:1/30～1/100000s |
| Focus length | 2.8~12mm/5-50mm |
| Optical focus | 4X / 10X optical zoom |
| Focus system | Auto focus |
| IR distance | 60m |
| IR light control | Intelligent control technology |
| IR light angle | Infrared zoom matching technology |
| IR light power | Manual setting |
| IR on | Day/Night/Auto |
| IR life | 30000hours |
| Horizontal range | 355°Continuous rotation |
| Vertical range | -90°~0° |
| Preset call speed | Max 40°/S |
| Manual call speed | 0.01°~180°/S |
| Presets | 40 pcs presets |
| Cruise track | 4 groups, each group for 10 presets |
| Patrol track | 2 groups, each group record 500 actions |
| Video compression | H.264 Main Profile encoding, MJPEG / JPEG Baseline encoding |
| Audio compression | G.711, G.726 |
| Primary stream | 1920 * 1080P, 25fps |
| Secondary stream | 704*576，352*288，320*240，25fps |
| Video bit rate | 32Kbps-16Mbps continuously adjustable, support CBR / VBR |
| Network protocol | TCP/IP、UDP、RTP、RTSP、RTCP、HTTP、DNS、DDNS、DHCP、FTP、NTP、PPPOE、SMTP、UPNP |
| ONVIF support | Support |
| Cooling Structure | Dustproof structure outside the circle |
| protection level | IP66 |
| Power supply | DC12V/3A |
| Power | 35W |
| Weight | 2.5KG |
| Work temperature | -35-65℃ |
